Solid Wood Rip Saw And DD Saw ATB Saw Blade

Send Inquiry

Request To Call Back

Solid Wood Rip Saw And DD Saw ATB Saw Blade

Get a Price/Quote

MOQ : 100 Pieces

Solid Wood Rip Saw And DD Saw ATB Saw Blade Specification

Operate Method
Mount on compatible sawing machines

Operation Type
Manual & Machine operated

Coating Type
Anti-corrosive

Cutting Capacity
Up to 60 mm (varies by model)

Features
Anti-kickback design, Laser-cut expansion slots, Low vibration, Smooth finish

Cutter Type
Tungsten Carbide-Tipped Teeth

Drill Bits Types
ATB (Alternate Top Bevel) Saw Blade

Cutting Speed
Up to 6,000 RPM

Cutting Accuracy
High Precision

Machine Type
Table Saw, Panel Saw, Sliding Table Saw

Tool Type
Circular Saw Blade

Coating
Non-stick (anti-resin & anti-friction)

Cutting Force
High - optimized for solid wood ripping and cross cutting

Shape
Circular

Hardness
Up to HRC 48-52

Brooches Type
Solid Wood Rip Saw & Double Dish (DD) Saw

Length
N/A (circular blade)

Material
Others

Diameter
250 mm, 300 mm, 350 mm, 400 mm (available sizes)

Maximum Torque
Suitable for heavy-duty table and panel saws

Processing Type
Finishing

Quality Standard
Conforms to industrial safety and precision norms

Noise Reduction
Laser-cut sound dampening slots

Finish Type
Mirror finish for reduced friction

Application
Ideal for solid wood rip and crosscut operations

Bore Diameter
30 mm (other sizes available upon request)

Number of Teeth
24T, 30T, 40T (varies per blade size)

Kerf Thickness
2.8 mm to 3.5 mm (varies by model)

Heat Resistance
High, prevents blade warping

Re-sharpenable
Yes, suitable for multiple regrinds

Suitable Materials
Hardwood, Softwood, Laminated Boards

Solid Wood Rip Saw And DD Saw ATB Saw Blade Trade Information

Minimum Order Quantity
100 Pieces

Payment Terms
Cash in Advance (CID)

Supply Ability
1000 Pieces Per Month

Delivery Time
2-5 Days

Main Domestic Market
All India

About Solid Wood Rip Saw And DD Saw ATB Saw Blade

CODE	DIA	THICKNESS	BORE SIZE	TEETH
SGRD10-1	250	3.2mm	63.5mm	48
SGRD12-1	300	3.2mm	63.5mm	48
SGRD12-2	300	3.2mm	25.4mm	56
SGRD12-3	300	3.2mm	25.4mm	72
SGRD12-4	300	3.2mm	25.4mm	96
SGRD12-5	300	5.0mm	25.4mm	48
SGRD12-6	300	6.0mm	25.4mm	48
SGRD13-1	330	3.5mm	63.5mm	48
SGRD13-2	330	3.5mm	25.4mm	56
SGRD13-3	330	3.5mm	63.5mm	56
SGRD13-4	330	5.0mm	25.4mm	56
SGRD13-5	330	6.0mm	25.4mm	56
SGRD14-1	350	3.5mm	25.4mm	36
SGRD14-2	350	3.5mm	25.4mm	56
SGRD14-3	350	3.5mm	63.5mm	56
SGRD14-4	350	3.5mm	25.4mm	60
SGRD14-5	350	3.5mm	25.4mm	72
SGRD14-6	350	3.5mm	25.4mm	84
SGRD14-7	350	3.5mm	25.4mm	96
SGRD14-8	350	3.5mm	25.4mm	108
SGRD16-1	400	3.5mm	25.4mm	60
SGRD16-2	400	3.5mm	25.4mm	96
SGRD16-3	400	3.5mm	25.4mm	108
SGRD16-4	400	3.5mm	25.4mm	120
SGRD16-5	400	3.5mm	25.4mm	132
SGRD18-1	450	3.6mm	25.4mm	54
SGRD18-2	450	3.6mm	25.4mm	72
SGRD18-3	450	3.6mm	25.4mm	108
SGRD18-4	450	3.6mm	25.4mm	120

Machine : Rip Saw & DD Saw machine
Application: Solid Wood
Advantage : Convenient, effective, safe etc.

Spotlight on our hot-selling Solid Wood Rip Saw and DD Saw ATB Saw Blades-crafted to dominate wood processing operations with towering performance. Engineered from grandiose premium alloy steel and equipped with tungsten carbide-tipped teeth, these blades excel in both solid wood ripping and crosscutting. Available in 24T, 30T, and 40T variants with precise kerf thickness, they boast a mirror finish and anti-corrosive coating, minimizing friction and heat. Grand safety features like anti-kickback and laser-cut expansion slots guarantee safe, accurate cuts. Suitable for heavy-duty table, panel, and sliding table saws, our blades ensure high precision, smooth finishes, and longevity. Clearance pricing available for select sizes-exporter, manufacturer, and supplier from India.

Surface Application & Machine Features

The Solid Wood Rip Saw and DD Saw ATB Saw Blade is ideal for hardwood, softwood, and laminated board processing. With a high-precision, mirror-finished blade, it reduces friction and heat, delivering smooth cuts. Mount easily on compatible table saws, panel saws, and sliding saws for manual or machine operation. Features like anti-kickback design, laser-cut sound dampening, and low vibration contribute to unparalleled cutting force and exceptional finish quality across a maximum 60 mm cutting capacity.

Sample Policy & Payment Terms

We offer sample units of the Solid Wood Rip Saw and DD Saw ATB Saw Blade for evaluation before bulk purchases. Samples are dispatched promptly upon confirmed request, often at the prevailing list price. Flexible payment terms are available for both domestic and international customers, ensuring a seamless trial and procurement process. Detailed terms and special offers for bulk orders may apply-contact our export team for tailored arrangements.

FAQ's of Solid Wood Rip Saw And DD Saw ATB Saw Blade:

Q: How does the Solid Wood Rip Saw and DD Saw ATB Saw Blade improve cutting accuracy and finish?

A: Equipped with tungsten carbide-tipped teeth and a mirror finish, these blades deliver high-precision cuts and reduce friction and heat, resulting in smoother, cleaner edges for both rip and crosscut applications.

Q: What materials can be processed using this saw blade?

A: This blade is suitable for hardwood, softwood, and laminated boards, ensuring versatility for various woodworking operations.

Q: Where can these blades be installed and operated?

A: They are designed for use with heavy-duty table saws, panel saws, and sliding table saws, accommodating both manual and machine-assisted operation.

Q: What safety features are included in the blade's design?

A: Safety is prioritized through laser-cut sound dampening slots, an anti-kickback design, and low-vibration engineering to enhance user safety during operation.

Q: Can the saw blades be re-sharpened for extended use?

A: Yes, these blades are designed to be re-sharpened multiple times, prolonging their lifespan and providing cost-efficient performance.

Q: How quickly are sample blades dispatched for evaluation?

A: Samples are dispatched promptly upon request and order confirmation, allowing you to evaluate the blade's performance before making a bulk purchase.
